S-type single-stage double-suction centrifugal pump
Share to
- 产品描述
-
Product Introduction
S-type single-stage double-suction centrifugal pump (horizontal split pump), used for conveying clear water or other liquids with physical and chemical properties similar to water. According to user needs, by changing the pump structure and materials, it can be used for conveying water with high mud and sand content or various corrosive liquids. This series of pumps is suitable for factories, mines, urban water supply and drainage, power stations, agricultural irrigation and drainage, and various water conservancy projects.
Product Features
The suction port and discharge port of the S-type single-stage double-suction centrifugal pump are both below the pump shaft centerline, perpendicular to the axis in a horizontal direction. During maintenance, it is not necessary to remove the inlet and outlet water pipes and motor. Viewed from the direction of rotation, the pump rotates clockwise (it can also be changed to counterclockwise rotation according to user needs).
The main parts of the pump include: pump body, pump cover, impeller, shaft, double suction sealing ring, and sleeve, etc.
The pump body and pump cover constitute the impeller's working chamber. On the inlet and outlet water flanges, there are pipe screw holes for installing vacuum gauges and pressure gauges. At the bottom of the inlet and outlet water flanges, there are pipe screw holes for draining.
The impeller, which has undergone static balance calibration, is fixed on the shaft by the sleeve nuts on both sides of the sleeve, and its axial position can be adjusted through the sleeve nuts.
The pump shaft is supported by two single-row deep groove ball bearings. The bearings are installed in the bearing housing, mounted at both ends of the pump body, and lubricated with grease.
The double suction sealing ring is used to reduce water leakage from the pump pressure chamber back to the suction chamber.
The pump is directly driven by an electric motor through an elastic coupling. If necessary, an internal combustion engine can also be used for transmission.
The shaft seal is a soft packing seal (mechanical seal structure can be used according to user needs).
Model Significance
For example: 300S-90A-I
300 - Suction port diameter 300mm
S - Single-stage double-suction centrifugal pump
90 - Head 90m
A - Changes the pump model by changing the outer diameter of the impeller
I - Material code for the flow parts
Product System
The company's industrial pump production base focuses on meeting the needs of various industrial scenarios. We are committed to creating products such as slurry pumps, desulfurization pumps, dredging pumps, submersible pumps, and chemical pumps. From the demand for high wear-resistant slurry pumps in large-scale mining, to the dependence on high-efficiency desulfurization pumps in power plant desulfurization, to the strict requirements for high corrosion-resistant chemical pumps in fine chemical processes, we can provide high-performance products that are suitable for all. These pumps are widely used in industries such as mining, power plant desulfurization, river sand mining, metallurgy and steel, chemical industry, etc.
The valve production base covers various categories such as ball valves, gate valves, butterfly valves, etc. With excellent quality and reliable performance, it is widely used in the fields of oil and gas transmission pipelines, urban water supply and drainage systems, etc., to ensure the safe and stable operation of various fluid transmission systems.
